FAQs

Your ultimate resource for all things portable 12 volt fridge freezers.

• What are the power requirements for the MT-V Series

  All MT-V Series Fridge and Freezers support 12 volt, 24 volt & 240 volt operation with a DC power consumption variable from 0.5 – 3.0 AMPS MAX.

• Do you need to unplug the 12 volt fridge cord when plugging into 240 volt?

  The latest models (E & F Series) fridge / freezer will detect when 240 volt is now available and select it, leaving you battery alone. Same in reverse simply unplug the 240 volt lead and the fridge will switch back onto 12 volt keeping everything cold with out you needing to lift a finger.

• How do you plug my Engel into 24 volt?

  It is recommended that you use the Engel Posi-fit connection for connection to a 24 volt system. This fitting is supplied with your 12 volt lead as standard, simply unscrew your cigar lighter fitting and this will expose the pos-fit connection two pins with a keyway to prevent incorrect polarity damage, and also has a screw on flange to prevent the fitting vibrating out. This is the best fitting for all your off road uses. Please refer to the Posi-Fit connection under fridge accessories. Part Number # ASPAN, APAN, BPAN, MPAN, NPAN.

• Why are Engel Fridge and Freezers power efficient.

  Engel has the unique super efficient Sawafuji swing motor, with only one moving part, making it simply the most efficient motor available. The motor is self lubricating, works at 100% efficiency even at an angle of 30 degrees, and will keep running even as low as 10 volts.

• What features are included with the MT-V Series

  • DC Power Consumption: Variable from 0.5 – 3.0 AMPS
  • Power: Built-in 240V AC/12V/24V DC
  • On/off reed switch installed for the interior LED light
  • Robust corner protectors & handles
  • Larger lockable door latch for ease of access
  • Stronger reinforced baskets
  • Five years Warranty

• Do Engel fridges need to be perfectly flat and level when running?

  Unlike other brands of portable fridges, Engel doesn’t need to be level to perform. Engel has a unique compressor that is designed to be portable, the famous Sawafuji Swing Motor (please refer to the Swing Motor link on the right) it can run up to a 30 degree angle without losing efficiency.

• How cold will my Engel fridge get?

  An Engel chest type fridge / freezer can be used for either a fridge or a freezer it’s just a matter of adjusting the thermostat. Set to freeze number 5 on the dial it will get to approximately minus 18 degrees C.

• What type of compressor does Engel use?

  Engel’s World Famous Sawafuji Swing Motor Unique to Engel this purpose built compressor is designed to be a portable refrigeration compressor and is one of the key reasons why ENGEL is ‘A LEGEND IN RELIABILITY’. What is the first rule in engineering? – Keep it simple! The Sawafuji Swing Motor is a true reciprocating compressor; it has only one moving part. It doesn[squote]t get any simpler. The piston is connected to an electro dynamic device which is powered by the use of magnetic fields. With this technology there is no need for bearings, cranks or con-rods, so less moving parts means less chance of failure. With only one moving part there is a very low friction loss which means this is a highly efficient compressor. It has no high start up current draw because when it starts up it can simply move down just a fraction then return. Then it slowly increases the distance the piston travels each stroke until it reaches a full stroke. The Sawafuji Swing Motor does not need to perform a full stroke on start up unlike many rotary type compressors that must perform a complete cycle and need much more current to start. Because this is purpose built and designed to be a portable refrigerator compressor it has to be engineered to take the harshest of Australian conditions. The Sawafuji Swing Motor is located inside the compressor casing with pins locating in rubber bushes then suspended in between shock absorbent springs. It operates at 30 degrees angles and on rough corrugated tracks without losing efficiency. The leading brand for over 40 Years, only ENGEL portable fridge-freezers guarantee to go anywhere. Their reputation speaks for itself. ENGEL’s commitment to continuous improvement means that the ENGEL of today is the most reliable, the most efficient ever, quieter and full of features to ensure it is easier to use than ever before.
